Dayton MCA2258 Bi-Amplifier
Dayton MCA2258 Bi-Amplifier
Dayton Audio's MCA2258 Bi-Amplifier was designed for use in active 2-way loudspeakers for music playback, computer sound systems, and home theater applications. Independent high and low level controls and switchable bass boost enable customization to any listening environment. The amplifier includes comprehensive internal protection against shorted speaker loads, thermal faults, and overload conditions. Low frequency output specifications: *Minimum speaker impedance: 4 ohms *Power output: 40 watts RMS 8 ohms, 58 watts RMS 4 ohms *Frequency response: 15 Hz-3 kHz *THD: Less than 0.05%  rated power *S/N ratio: 80 dB *Bass boost frequency: 4 dB from 20 Hz to 200 Hz. High frequency output specifications: *Minimum speaker impedance: 4 ohms *Power output: 15 watts RMS  8 ohms, 22 watts RMS  4 ohms *Frequency response: 3 kHz-20 kHz *THD: Less than 0.05%  rated power *S/N ratio: 80 dB. Dimensions: *Overall: 5-3/8" W x 8-5/8" H x 4-1/2" D; Enclosure cutout: 4-5/8" W x 7-3/4" H.
  • Easily adjustable separate low/high amps for improved dynamic range
  • Independent LM3886 output devices
  • Master level control
  • Independent high and low level controls
  • Switchable 4 dB bass boost
  • 24 dB/octave low pass and high pass filters
  • 3 kHz crossover frequency
  • Line level inputs
  • Thermal, overload, and fuse protection circuitry
Email Friend

Product Question
List Price: $149.99
Your Price: $98.21
Out of Stock
