Dual channel
Dual trace
6" rectangular CRT with internal graticule
2KV acceleration voltage
High sensitivity 1mV/div
Display modes: CH-1, CH-2, DUAL, ALT, CHOP, ADD, CH-2 INV
Input coupling: AC/GND/DC
CH-1 output signal
Sweep modes: A, X—Y, X10 magnification
Trigger modes: AUTO, NORM, TV—V, TV—H
Trigger sources: CH-1, CH-2, ALT, LINE, EXT
Trigger slope: + or —
Z axis input for intensity modulation
Power requirements: 115/230VAC, 50/60Hz
Includes two 10:1 probes and owners manual

Features:
Specifications
Vertical bandwidth     DC coupled: DC~20MHz(-3dB) AC coupled: 10Hz~20MHz(-3dB)
Sensivity     5mV/div~5V/div (10 steps 1-2-5 sequence)
Rise time     17.5ns
Input impedance     1M ohm shunted by 25pF
Maximum input voltage     300V (DC + AC peak)
Horizontal sweep     Time base: 0.2us/div~0.5s/div (20 steps 1-2-5 sequence)
Dimensions/weight     12 1/4" (W) x 5 1/4" (H) x 19" (D)/19 lbs.
